B2B Ball Rescuer Padel Backpack Supplier
This backpack is engineered for padel facilities that need a reliable method to collect, transport, and store balls during training sessions and match play. The design focuses on load distribution,
B2B Ball Rescuer Padel Backpack
This backpack is engineered for padel facilities that need a reliable method to collect, transport, and store balls during training sessions and match play. The design focuses on load distribution, weather resistance, and quick access to minimize downtime between drills.
Design & Materials
The main body uses 600D polyester woven with a polyurethane coating, providing a tensile strength of approximately 45 MPa and a water resistance rating of IPX4. Reinforced stitching at stress points uses bonded nylon thread with a break strength of 22 kg. The base panel incorporates a 2 mm EVA foam layer to absorb impact when the bag is set down on hard surfaces.
- External dimensions: 45 cm (H) × 30 cm (W) × 20 cm (D)
- Internal volume: approximately 27 L
- Empty weight: 1.2 kg
- Maximum load capacity: 15 kg (≈ 120 standard padel balls)
Functional Features
A top‑opening zipper with a self‑repairing coil allows rapid insertion and retrieval of balls. The zipper pull is coated with a low‑friction polymer to reduce wear over 10,000 cycles. Interior mesh pockets (two, each 12 cm × 8 cm) hold accessories such as grips, wristbands, or small tools. Side compression straps with quick‑release buckles enable volume adjustment when the bag is partially filled.
Ventilation is provided by two laser‑drilled side panels (0.8 mm diameter holes, 200 per dm²) that promote airflow while maintaining structural integrity. The shoulder straps are 50 mm wide, padded with 10 mm closed‑cell foam, and adjustable via a ladder‑lock system rated for 25 kg load.
Technical Specifications
| Parameter | Typical Value |
|---|---|
| Fabric weight | 600D polyester with PU coating |
| Water resistance | IPX4 (splash proof from any direction) |
| Zipper life | ≥ 10,000 cycles (self‑repairing coil) |
| Stitch tensile strength | 22 kg per stitch (bonded nylon) |
| Load capacity | 15 kg (≈ 120 balls) |
| Temperature range | -20 °C to +60 °C (material flexibility retained) |
Applications
Clubs and academies use this backpack to streamline ball collection after drills, reducing the need for manual picking and decreasing wear on court surfaces. Coaches appreciate the ability to transport a full set of balls to multiple courts without repeated trips to the storage room. Facility managers benefit from the bag’s durability, which lowers replacement frequency compared with standard canvas carriers.
Quality Control Philosophy
Each unit undergoes a three‑stage inspection: material verification (fabric weight and coating thickness), seam integrity (pull test to 18 kg), and functional validation (zipper cycle test and load simulation). Inspection criteria are documented in a QC checklist that references ISO 9001‑2015 clause 8.6 for traceability. Non‑conforming items are segregated and reworked before shipment.
Customization Options
Clients may specify alternative fabric densities (800D or 1000D) for increased abrasion resistance, choose from a range of Pantone‑matched colors for branding, or add reflective strips for low‑light visibility. Interior pocket layout can be rearranged upon request, and the bottom panel can be upgraded to a water‑proof TPU laminate for wet environments.
Frequently Asked Questions
Yes, length, width, and depth can be adjusted within ±5 cm to suit specific storage constraints; please provide the required internal volume when requesting a quote.
Required details include desired fabric density, color preference, any logo placement, quantity, and delivery destination. Optional details: special accessories, packaging preferences, and required certifications.
Inspection includes fabric weight verification, seam pull testing, zipper endurance cycling, and load‑bearing simulation. Results are recorded per unit and available for review upon request.
Standard packaging is a single‑wall corrugated carton with internal polyethylene bag. Options include double‑wall cartons for extra protection or palletized packing for bulk orders.
Lead time ranges from 18 to 25 working days after artwork approval, depending on order size and customization complexity.
Contact Us
For technical inquiries, quotation requests, or sample arrangements, please reach out to our engineering team via the contact form.
