Entry‑level paddles are designed to deliver consistent playability while keeping material costs low enough for bulk procurement by schools, community centers, and recreational leagues. The focus is on geometric stability, weight uniformity, and surface durability rather than premium performance enhancements.
The paddle consists of three primary zones: a polymer core, a composite face, and an over‑grip wrapped handle. Each zone is engineered to meet tolerance targets that ensure the paddle behaves predictably across a large batch.
A polypropylene honeycomb core with a cell diameter of 6 mm and a thickness of 12 mm provides a baseline stiffness of approximately 0.45 GPa. The core density is held between 0.9 and 1.0 g/cm³, which yields a paddle weight in the 210‑230 g range when combined with the face layers.
The faces are made from a single layer of 0.8 mm thick fiberglass reinforced polypropylene sheet. This construction delivers a surface hardness of about 70 Shore D and a coefficient of restitution around 0.55, suitable for beginner to intermediate play while resisting delamination under repeated impact.
A 2 mm wide thermoplastic polyurethane (TPU) edge guard is injection‑molded around the perimeter to prevent core exposure. The handle receives a 1.2 mm thick, perforated synthetic leather over‑grip sized to a 4.25 in circumference, providing a slip‑resistant interface that meets ISO 105‑B02 abrasion standards after 500 cycles.
Because the paddle’s weight distribution stays within ±15 g of the target mean, institutions can rely on uniform swing feel across dozens of units, reducing the need for player‑specific adjustments. The TPU edge guard mitigates chipping on concrete‑based courts, extending service life in high‑traffic environments such as school gymnasiums and community recreation centers where paddles are shared among many users.
Each paddle undergoes a three‑step inspection: dimensional verification with a coordinate measuring machine (±0.1 mm tolerance), face adhesion testing via a 90° peel test (minimum 1.2 N/mm), and weight sorting into ±5 g batches. Only units passing all three criteria are released to warehouse stock, ensuring a predictable performance envelope for bulk orders.
| Parameter | Typical Value | Notes |
|---|---|---|
| Weight | 210‑230 g | ±5 g tolerance |
| Length | 395 mm | ±2 mm |
| Width | 190 mm | ±2 mm |
| Core Thickness | 12 mm | Adjustable 10‑14 mm |
| Face Material | Fiberglass‑reinforced PP | 0.8 mm thickness |
| Grip Circumference | 4.25 in | Optional 4.0‑4.5 in |
To discuss your volume requirements, customization needs, or request a sample, please contact our sales team. We will provide a detailed technical quotation and lead‑time estimate based on your specifications.
