Product Overview

Each net system consists of a high‑tensile polyethylene mesh, a galvanized steel frame, and a ground‑anchor kit that resists uplift from wind and ball impact.

The frame utilizes 48 mm oval tubing with a wall thickness of 2 mm, providing a bending resistance of approximately 1.8 kN·m under a 150 kg lateral load.

Key Technical Specifications

Materials and Construction

The mesh is manufactured from UV‑stabilized high‑density polyethylene (HDPE) with a denier of 1500 D and a tensile strength of not less than 55 MPa.

Frame tubes are pre‑galvanized, then coated with a zinc‑rich primer and a polyester powder coat (minimum thickness 80 µm) to achieve a corrosion resistance rating of 500 hours salt spray per ASTM B117.

Anchor kits include M10 × 150 mm galvanized steel bolts, nylon washers, and a concrete‑set epoxy that develops a shear strength of 22 MPa after 24 h curing.

Applications and Performance

Driveway installations experience cyclic loading from ball impact (up to 30 J per strike) and wind uplift (up to 0.6 kN·m). The net’s mesh elongation under 500 N load remains below 2 %, ensuring consistent play height.

Typical use cases include residential recreation zones, community sports complexes, and school multi‑use courts where a permanent, low‑maintenance barrier is preferred over portable systems.

Because the frame is anchored directly into the substrate, there is no need for periodic re‑tensioning; maintenance is limited to annual visual inspection of the mesh and coating integrity.

Quality Assurance and Testing

Each batch undergoes tensile testing of the mesh per ASTM D5035, with a minimum average break force of 250 N per 50 mm width.

Frame tubes are inspected for coating thickness using a magnetic inductance gauge; acceptance criterion is ≥70 µm zinc plus ≥80 µm powder coat.

Anchor pull‑out resistance is verified on concrete cylinders (MPa 30) following ASTM C90, confirming a minimum ultimate load of 2.5 kN per anchor.

Customization Options

• Frame color: standard safety yellow, white, or custom RAL.
• Mesh density: 1500 D (standard) or 1800 D for increased wind load resistance.
• Anchor type: straight bolt, L‑shaped, or epoxy‑set plate for high‑wind zones.
• Net length: 5.0 m to 7.0 m in 0.5 m increments to fit non‑standard driveways.
• Additional accessories: tension ratchet, protective edge padding, UV‑resistant cover.

Frequently Asked Questions

Can dimensions be customized?

Yes. Net width, height, and frame length are adjustable per project requirements; custom lengths are quoted after receipt of site drawings.

What information is required before quotation?

We need driveway substrate type (concrete/asphalt), thickness, desired net dimensions, and any local wind load specifications.

How is quality inspected?

Each shipment includes a test report covering mesh tensile strength, frame coating thickness, and anchor pull‑out resistance.

What packaging methods are available?

Frames are bundled with protective poly‑foam corners, mesh is rolled on a rigid core, and anchors are packed in sealed poly‑bags; palletized for LTL or FCL shipments.

What is the typical production lead time?

Standard configurations ship within 3‑4 weeks after order confirmation; custom projects require 5‑6 weeks.
